105SL Parts Catalog

Drive System Components

Item

Number

Description Part Number

Kit

Quantity

1 Kit DC Stepper Motor w/Pulley 203 DPI G46198M 1

1 Kit DC Stepper Motor w/Pulley 300 DPI G46199M 1

2 Main Drive Belt 45189-5 1

3 Media Rewind Belt 45189-2 1

4 Kit Platen Pulley 40355M 1

5 Kit Peel Roller Pulley 30914M 1

6 Kit Pulley for Media Take Up & Ribbon Take Up 31336M 1

7 Rewind Idler Pulley 30265 1

Idler Pulley Shaft 30207 1

1 2 3 4 5 6 7 8
