105SL Parts Catalog

Media Guide - Snap Plate - Media Bin - Tear Bar

Item

Number

Description Part Number

Kit

Quantity

1 Kit Media Guide G40305RM 1

2 Upper Media Guide Plate (Snap Plate) 48043-2 1

Kit Internal Fan-Fold Supply Bin G40457 1

Peel/Tear Bar 32415 1

Liner Rewind Components

Item

Number

Description Part Number

Kit

Quantity

Kit Upgrade Liner Rewind G33180 1

Ribbon/Liner Take-Up Teflon J Hook 40490-2 1

Media Rewind Components

Item

Number

Description Part Number

Kit

Quantity

Kit Upgrade Media Rewind G33181 1

Kit Maintenance Media Rewind Spindle G40055RM 1

Kit Media Rewind Plate G40383RM 1

Media Rewind Hook 47062-2 1

7

1 2 3 4 5 6 7 8

105SL Parts Catalog 1
